IRM-90-48
90W 48VDC 1.88A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- Cooling by free air convection
- No load power consumption < 0.3W
- EMI compliance: BS EN/EN55032 Class B without additional components
- PCB, chassis, or screw terminal mounting version
- 100W peak load (10 seconds)
- Isolation Class II
- Operating altitude up to 4000 meters (Note 7)
- Overvoltage category III
- Wide operating temperature range: -30~+80°C
- 3.43” × 2.05” compact size
- Universal input: 80~305VAC
- 3 years warranty
Description
The MEAN WELL IRM-90-48 is a 90W AC-DC PCB-mount green power module designed for compact embedded power applications requiring a regulated 48VDC output. It provides 1.88A convection output with 90.2W rated power, plus up to 2.07A and 99.2W peak output for 10 seconds, accepting a universal 80-305VAC input and 113-431VDC input for flexible integration into PCB-based equipment designs. The unit features a compact 87 x 52 x 29.5mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.3W, free air convection cooling, overvoltage category III, operating altitude up to 4000 metres and protection against short circuit, overload, overvoltage and overtemperature. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
