IRM-90-24
90W 24VDC 3.75A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- Operating altitude up to 4000 meters (Note 7)
- Overvoltage category III
- Universal input: 80~305VAC
- PCB, chassis, or screw terminal mounting version
- Wide operating temperature range: -30~+80°C
- 3.43” × 2.05” compact size
- 3 years warranty
- No load power consumption < 0.3W
- Cooling by free air convection
- EMI compliance: BS EN/EN55032 Class B without additional components
- 100W peak load (10 seconds)
- Isolation Class II
Description
The MEAN WELL IRM-90-24 is a 90W AC-DC PCB-mount green power module designed for compact embedded power applications requiring a regulated 24VDC output. It provides 3.75A convection output with 90W rated power, plus up to 4.13A and 99W peak output for 10 seconds, accepting a universal 80-305VAC input and 113-431VDC input for flexible integration into PCB-based equipment designs. The unit features a compact 87 x 52 x 29.5mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.3W, free air convection cooling, overvoltage category III, operating altitude up to 4000 metres and protection against short circuit, overload, overvoltage and overtemperature. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
