IRM-90-15ST
85W 15VDC 5.67A PCB Mount Encapsulated Power Supply with Screw Terminals Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- Wide operating temperature range: -30~+80°C
- 100W peak load (10 seconds)
- No load power consumption < 0.3W
- Isolation Class II
- Cooling by free air convection
- Operating altitude up to 4000 meters (Note 7)
- Universal input: 80~305VAC
- 3.43” × 2.05” compact size
- Overvoltage category III
- EMI compliance: BS EN/EN55032 Class B without additional components
- PCB, chassis, or screw terminal mounting version
Description
The MEAN WELL IRM-90-15ST is a 90W class AC-DC green power module supplied in a screw terminal mounting style for compact embedded power applications requiring a regulated 15VDC output. It provides 5.67A convection output with 85.05W rated power, plus up to 6.23A and 93.5W peak output for 10 seconds, accepting a universal 80-305VAC input and 113-431VDC input for flexible integration into equipment designs. The unit features a 109 x 52 x 33.5mm screw terminal package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.3W, free air convection cooling, overvoltage category III, operating altitude up to 4000 metres and protection against short circuit, overload, overvoltage and overtemperature. With anti-vibration capability up to 5G, it is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- Screw Terminal
