IRM-90-15
85W 15VDC 5.67A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- 100W peak load (10 seconds)
- EMI compliance: BS EN/EN55032 Class B without additional components
- Isolation Class II
- PCB, chassis, or screw terminal mounting version
- Overvoltage category III
- 3 years warranty
- 3.43” × 2.05” compact size
- Operating altitude up to 4000 meters (Note 7)
- Cooling by free air convection
- Universal input: 80~305VAC
- No load power consumption < 0.3W
- Wide operating temperature range: -30~+80°C
Description
The MEAN WELL IRM-90-15 is a 90W class AC-DC PCB-mount green power module designed for compact embedded power applications requiring a regulated 15VDC output. It provides 5.67A convection output with 85.05W rated power, plus up to 6.23A and 93.5W peak output for 10 seconds, accepting a universal 80-305VAC input and 113-431VDC input for flexible integration into PCB-based equipment designs. The unit features a compact 87 x 52 x 29.5mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.3W, free air convection cooling, overvoltage category III, operating altitude up to 4000 metres and protection against short circuit, overload, overvoltage and overtemperature. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
