IRM-45-24
45W 24VDC 1.9A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- EMI Class B without additional components
- 3 years warranty
- No load power consumption < 0.15W
- Wide operating temperature range: -30~70°C
- Overvoltage category II
- Pass LPS (Except for 5V)
- 3.43” × 2.05” compact size
- Cooling by free air convection
- Isolation Class II
- PCB, chassis or screw terminal mounting version
- Universal input: 85~305VAC
Description
The MEAN WELL IRM-45-24 is a 45W AC-DC PCB-mount green power module designed for compact embedded power applications. It provides a regulated 24VDC output with a 1.9A rated current and 45.6W rated power, accepting a universal 85-305VAC input for flexible integration into PCB-based equipment designs. The unit features a compact 87 x 52 x 29.5mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.15W, free air convection cooling, overvoltage category III and protection against short circuit, overload and overvoltage. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
