IRM-45-15
45W 15VDC 3A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- EMI Class B without additional components
- 3 years warranty
- No load power consumption < 0.15W
- Universal input: 85~305VAC
- Wide operating temperature range: -30~70°C
- Cooling by free air convection
- 3.43” × 2.05” compact size
- Isolation Class II
- PCB, chassis or screw terminal mounting version
- Overvoltage category II
- Pass LPS (Except for 5V)
Description
The MEAN WELL IRM-45-15 is a 45W AC-DC PCB-mount green power module designed for compact embedded power applications. It provides a regulated 15VDC output with a 3A rated current and 45W rated power, accepting a universal 85-305VAC input for flexible integration into PCB-based equipment designs. The unit features a compact 87 x 52 x 29.5mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.15W, free air convection cooling, overvoltage category III and protection against short circuit, overload and overvoltage. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
