IRM-30-5ST
30W 5VDC 6A PCB Mount Encapsulated Power Supply with Screw Terminals Please ring us to discuss a great price for this product.Product Features
- 2.74" × 1.54" compact size
- Over voltage category III
- Cooling by free air convection
- EMI Class B without additional components
- No load power consumption < 0.1W
- Universal input: 85–305VAC
- 3 years warranty
- Isolation Class II
- PCB, chassis or screw terminal mounting version
- Pass LPS (except for 5V)
Description
The MEAN WELL IRM-30-5ST is a 30W AC-DC green power module supplied in a screw terminal mounting style for compact embedded power applications. It provides a regulated 5VDC output with a 6A rated current and 30W rated power, accepting a universal 85-305VAC input for flexible integration into equipment designs. The unit features a 91 x 39.5 x 28.5mm screw terminal package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.1W, free air convection cooling, overvoltage category III and protection against short circuit, overload and overvoltage. With anti-vibration capability up to 5G, it is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- Screw Terminal
