IRM-15-5
15W 5VDC 3A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- 2.06" x 1.07" compact size
- Universal input: 85~305VAC
- Cooling by free air convection
- 3 years warranty
- EMI Class B without additional components
- No load power consumption < 0.1W
- Pass LPS
- Wide operating temperature range: -30~+70°C
- Isolation Class II
Description
The MEAN WELL IRM-15-5 is a miniature AC-DC PCB-mount green power module designed for compact low-power electronic equipment. It provides a regulated 5VDC output with a 3A rated current and 15W rated power, accepting a universal 85-305VAC input and 120-430VDC input for flexible integration into PCB-based designs. The unit features a compact 52.4 x 27.2 x 24mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.1W, free air convection cooling and protection against short circuit, overload and overvoltage. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
