IRM-10-24
10W 24VDC 0.42A PCB Mount Encapsulated Power Supply Please ring us to discuss a great price for this product.Product Features
- 1.8" × 1" compact size
- Isolation Class II
- Universal input: 85~305VAC
- Cooling by free air convection
- EMI Class B without additional components
- No load power consumption < 0.1W
- Pass LPS
- Wide operating temperature range: -30~+70°C
- 3 years warranty
Description
The MEAN WELL IRM-10-24 is a miniature AC-DC PCB-mount green power module designed for compact low-power electronic equipment. It provides a regulated 24VDC output with a 0.42A rated current and 10.08W rated power, accepting a universal 85-305VAC input and 120-430VDC input for flexible integration into PCB-based designs. The unit features a compact 45.7 x 25.4 x 21.5mm encapsulated package, Class II design with no FG pin, built-in EMI filtering components, low no-load power consumption below 0.1W, free air convection cooling and protection against short circuit, overload and overvoltage. It is suitable for industrial electrical equipment, mechanical equipment, factory automation equipment and handheld electronic devices.
Style
- PCB
