LOP-300-54
300W 80 ~ 264VAC 54VDC 3.3A 4""x2"" Low Profile Open Frame Power Supply Please ring us to discuss a great price for this product.Product Features
- Suitable for Class I or Class II installations
- 40ºC ~ +80°C wide range operation temperature
- 3 years warranty
- Protections: Short circuit / Overload / Over voltage / Over temperature
- 180W convection, 300W with FAN 10.98CFM forced-cooled
- 4"x2" compact size with low profile (25.4mm)
Description
The MEAN WELL LOP-300-54 is a 300W class low profile open frame power supply designed for compact equipment requiring a regulated 54VDC output, including power sourcing equipment for PoE applications. It delivers 5.6A and 302.4W with 10.98CFM forced-air cooling, 3.4A and 183.6W under free air convection, and supports an 8.3A / 450W peak load for 3 seconds. The unit accepts 80-264VAC input with built-in PFC, provides 94% typical efficiency and includes a 54V output adjustment range of 52V to 58V. With a compact 101.6 x 50.8 x 25.4mm open frame design, low no-load power consumption below 0.5W, 12V/0.5A external fan supply, low leakage and touch current, Class I or Class II installation suitability, 2xMOPP isolation and protection against short circuit, overload, overvoltage and overtemperature, the LOP-300-54 is suitable for PoE equipment, industrial automation, security, medical, network, telecom and electronic equipment applications.
