LOP-300-36
300W 80 ~ 264VAC 36VDC 5A 4""x2"" Low Profile Open Frame Power Supply Please ring us to discuss a great price for this product.Product Features
- Protections: Short circuit / Overload / Over voltage / Over temperature
- 180W convection, 300W with FAN 10.98CFM forced-cooled
- Suitable for Class I or Class II installations
- 3 years warranty
- 40ºC ~ +80°C wide range operation temperature
- 4"x2" compact size with low profile (25.4mm)
Description
The MEAN WELL LOP-300-36 is a 300W class low profile open frame power supply designed for compact equipment requiring a regulated 36VDC output. It delivers 8.3A and 299.8W with 10.98CFM forced-air cooling, 5A and 180W under free air convection, and supports a 12.5A / 450W peak load for 3 seconds. The unit accepts 80-264VAC input with built-in PFC, provides 94% typical efficiency and includes a 36V output adjustment range of 34.2V to 37.8V. With a compact 101.6 x 50.8 x 25.4mm open frame design, low no-load power consumption below 0.5W, 12V/0.5A external fan supply, low leakage and touch current, Class I or Class II installation suitability, 2xMOPP isolation and protection against short circuit, overload, overvoltage and overtemperature, the LOP-300-36 is suitable for industrial automation, security, medical, network, telecom and electronic equipment applications.
