XDR-150E-12
150W 12VDC Economical Ultra Slim Industrial DIN Rail Power Supplies Please ring us to discuss a great price for this product.Product Features
- 3 years warranty
- Built-in DC OK relay contact
- High efficiency up to 91% and no load power dissipation <1W
- Protections: Short circuit / Overload / Over voltage / Over temperature
- Fanless design, cooling by free air convection
- 40~+70°C wide range operation temperature (>+50°C derating)
- Operating altitude up to 5000 meters
- L116 x W30 x H125.2mm
- 85~264Vac input range
Description
The MEAN WELL XDR-150E-12 is an AC/DC economical ultra slim industrial DIN rail power supply designed for compact control panels and industrial equipment requiring a regulated 12VDC output. It delivers 10A and 120W at 115VAC input, or up to 11A and 132W at 230VAC input, with an adjustable output range of 12V to 15V. The unit accepts 85-264VAC input and 120-370VDC input, provides 89% typical efficiency and uses fanless free air convection cooling to support reliable operation in enclosed systems. With a 30 x 125.2 x 116mm slim DIN rail housing, built-in constant current limiting, DC OK relay contact, overvoltage category III, operation from -40°C to +70°C with derating and protection against short circuit, overload, overvoltage and overtemperature, the XDR-150E-12 is suitable for industrial control systems, factory automation, semiconductor fabrication equipment, electro-mechanical apparatus and battery charger applications.
